AIRCRAFT
Aircraft Specifications
Takeoff Weight	1127g (EVO II) 1174g (EVO II Pro) 1157g (EVO II Dual 320) 1192g (EVO II Dual 640)
Dimensions	Folded: 228133110 mm (length×width×height) Unfolded: 424354110 mm (length×width×height)
Diagonal Distance	397 mm
Max Ascent Speed	Standard mode: 5 m/s Ludicrous mode: 8 m/s
Max Descent Speed	Standard mode: 3 m/s Ludicrous mode: 4 m/s
Max Speed (near sea level, no wind)	Standard mode: 15 m/s Ludicrous mode: 20 m/s
Max Service Ceiling Above Sea Level	7000 m
Max Flight Time (no wind)	40 minutes
Max Hovering Time (no wind)	35 minutes
Max Flight Distance (no wind)	25 km
Max Wind Speed Resistance	Level 8
Max Tilt Angle	Standard mode: 28° Ludicrous mode：33°
Max Angular Velocity	120°/s
Operating Temperature Range	-10°C to 40°C
Operating Frequency	2.4~2.4835GHz
Transmission Power (EIRP)	2.4~2.4835GHz FCC: ≤26 dBm ISED: ≤26 dBm CE: ≤20 dBm RCM: ≤20 dBm SRRC: ≤26 dBm
GNSS	GPS/GLONASS/VIO/ATTI
Hovering Accuracy Range	Vertical: ± 0.02 m (when vision positioning is active) ± 0.2 m (with GPS positioning) Horizontal: ± 0.02 m (when vision positioning is active) ± 1.0 m (with GPS positioning)
Internal Storage	8 GB
SD Storage	Standard: 32 GB, max. support 256GB

Camera Specifications

Model Name

EVO II

EVO II Pro

EVO II Dual


Sensor

1/2″ CMOS
Effective Pixels: 48 million
Performance temperature: -20 ~ 60 ℃

1″ CMOS
Effective Pixels: 20 million
Performance temperature: -10 ~ 60 ℃

1/2″ CMOS 48 million +
FLIR LWIR Sensor 640*512 (320*256 optional)

Lens

FOV: about 79°
35 mm Format Equivalent: 25.6 mm
Aperture: f/1.8
Shooting Range: 0.5 m to ∞

FOV: about 77°
35 mm Format Equivalent: 28.6 mm @f/2.8
Aperture: f/2.8–f/11
Shooting Range: 1 m to ∞

Infrared Camera:
FOV 32°, 14 mm lens combined with FLIR 640*512 sensor
FOV 34°, 6.3 mm lens combined with FLIR 320*256 sensor

ISO Range

Video: ISO100~3200 (Auto)
Video: ISO100~3200 (Manual)
Photo: ISO100~3200 (Auto)
Photo: ISO100~3200 (Manual)

Video: ISO100~3200 (Auto)
Video: ISO100~6400 (Manual)
Photo: ISO100~3200 (Auto)
Photo: ISO100~12800 (Manual)

Visible Light & Picture in Picture (PiP) Mode:
ISO100~3200 (Auto)
ISO100-3200 (manual)

Infrared：N/A

Shutter Speed

Electronic Shutter: 8 ~ 1/8000s

Visible Light & Picture in Picture (PiP) Mode: 8 ~ 1/8000s

Digital Zoom

1 ~ 8x (Max. 4x lossless zoom)

1 ~ 8x (Max. 3x lossless zoom)

1 ~ 8x (Max. 4x lossless zoom of Visible Light mode)

Still Image Resolution

8000*6000 (4:3)

5472*3648 (3:2)

Visible Light mode: same as EVO II
Infrared mode: 640*512
Picture in Picture mode: 1920*1080, 1280*720

7680*4320 (16:9)

5472*3076 (16:9)

4000*3000 (4:3)

3840*2160 (16:9)

Still Image Format

JPEG / DNG / JPEG+DNG

Visible Light mode: same as EVO II
Infrared & Picture in Picture mode: JPEG

Still Photography Modes

Single shot
Burst shooting: 3/5 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
Time Lapse: JPG: 2s/5s/7s/10s/20s/30s/60s
DNG: 5s/7s/10s/20s/30s/60s
HyperLight: support (under 4K JPEG format)
Long exposure: Max. 8s
HDR imaging: support (under 4K JPEG format)

Visible Light mode: same as EVO II
Infrared & Picture in Picture mode: Single shot, Burst shooting, Time Lapse

Video Resolution

7680*4320   p25/p24
5760*3240   p30/p25/p24
3840*2160   p60/p50/p48/p30/p25/p24
2720*1528   p120/p60/p50/p48/p30/p25/p24
1920*1080   p120/p60/p50/p48/p30/p25/p24

5472*3076   p30/p25/p24
3840*2160   p60/p50/p48/p30/p25/p24
2720*1528   p120/p60/p50/p48/p30/p25/p24
1920*1080   p120/p60/p50/p48/p30/p25/p24

Visible light mode: same as EVO II
Infrared mode: 640*512   p60 (US)
                          640*512   p9 (Other regions)
Picture in Picture mode: 1920*1080   p30
                                           1280*720   p30

Video format

MOV / MP4

Codecs

H.264 / H.265

Max Video Bitrate

120Mbps

HDR Video Recording

support 3840*2160, 2720*1528, 1920*1080 HDR video recording

Visible Light mode: same as EVO II

PIV Capture

support

Hyperlapse Recording

support (coming soon)

AE Mode

Auto / Manual / Shutter Priority

Auto / Manual / Shutter Priority / IRIS Priority

Visible Light mode: same as EVO II

AE Measurement

Center weighted / Spot

Visible Light mode: same as EVO II

EV Compensation

±3EV 0.3EV/step

Visible Light mode: same as EVO II

AWB Mode

Auto / Manual (Sunny / Cloudy / Incandescent / Neon / Custom)

Visible Light mode: same as EVO II

AF Mode

Auto / Manual

Visible Light mode: same as EVO II

AF Range

0.5m ~ Infinity

1m ~ Infinity

Visible Light mode: same as EVO II

Assist Focus

support in MF mode

Visible Light mode: same as EVO II

Touch AE/AF

support

Visible Light mode: same as EVO II

AE/AF Lock

support

Visible Light mode: same as EVO II

Color Mode

None / Black & White / Nostalgic / Log (10-bit)

Visible Light mode: same as EVO II

Image Style

Standard / Neutral / Landscape / Custom

Visible Light mode: same as EVO II

Histogram

support

Visible Light mode: same as EVO II

Defog

support

Visible Light mode: same as EVO II

ROI

support

Visible Light mode: same as EVO II

SENSING SYSTEM
Sensing System Specifications
Sensing System	Omnidirectional Obstacle Sensing	Omnidirectional Obstacle Sensing includes left/right, up/down, forward/backward obstacle sensing. Omnidirectional Obstacle Sensing does not fully cover the circumference of a 360-degree arc. Please be aware of your surroundings and App notifications when operating the EVO Ⅱ to ensure safety. These specs have been determined through tests conducted with the latest firmware. Firmware updates can enhance performance, so updating to the latest firmware is highly recommended.
Forward	Precision Measurement Range: 0.5 – 20 m Detectable Range: 0.5 – 40 m Effective Sensing Speed: < 15m/s FOV: Horizontal: 60°, Vertical: 80°
Backward	Precision Measurement Range: 0.5 – 16 m Detectable Range: 0.5 – 32 m Effective Sensing Speed: < 12m/s FOV: Horizontal: 60°, Vertical: 80°
Upward	Precision Measurement Range: 0.5 – 12 m Detectable Range: 0.5 – 24 m Effective Sensing Speed: < 6m/s FOV: Horizontal: 60°, Vertical: 50°
Downward	Precision Measurement Range: 0.5 – 11 m Detectable Range: 0.5 – 22 m Effective Sensing Speed: < 6m/s FOV: Horizontal: 90°, Vertical: 70°
Sides	Precision Measurement Range: 0.5 – 12 m Detectable Range: 0.5 – 24 m Effective Sensing Speed: < 10m/s FOV: Horizontal: 60°, Vertical:50°
Operating Environment	Forward, Backward,Upward and Sides: Surface with clear pattern and adequate lighting (lux > 20) Downward: Surface with clear pattern and adequate lighting (lux > 20) Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.)

GIMBAL
Gimbal Specifications
Weight	70g (EVO II) 107g (EVO II Pro) 100g (EVO II Dual 320) 135g (EVO II Dual 640)
Mechanical Range	Pitch: -135~45°, Roll: -45~45°, Yaw: ±100°
Controllable Range	Pitch: -90~0°, Roll: /, Yaw: -90~90°
Stabilization	3-axis (pitch, roll, yaw)
Max Control Speed (tilt)	200°/s
Angular Vibration Range	±0.003° @ 10m/s ±0.008° @ 15m/s ±0.013° @ 20m/s

INTELLEGENT FLIGHT BATTERY
Aircraft Battery Specifications
Capacity	7100 mAh
Voltage	11.55 V
Max Charging Voltage	13.2 V
Battery Type	LiPo 3S
Energy	82 Wh
Net Weight	365 g
Charging Temperature Range	5℃ to 40℃
Max Charging Power	82 W

REMOTE CONTROLLER
Remote Control Specifications
Operating Frequency 2.4~2.4835Ghz
“Max Transmission Distance
(unobstructed, free of interference) ” “FCC: 9km
CE: 5km”
Operating Temperature Range -10℃ – 40℃
Transmission Power (EIRP) “2.4~2.4835GHz
FCC: ≤26 dBm
ISED: ≤26 dBm
CE: ≤20 dBm
RCM: ≤20 dBm
SRRC: ≤20 dBm “
Battery 5000 mAh
Weight 370g
Operating Current/Voltage 1.7A@3.7V
Charing Temperature Range 0 – 40℃
Supported Mobile Device Size “Max length: no limit;
Max width: 84mm;
Max thickness: 13mm; “
Supported USB Port Types Lightning, Micro USB (Type-B), USB-C
Operating hours 3 H
OLED NITS 330

CHARGER
Charger Specifications
Input	100-240 V, 50/60 Hz, 1.5A
Output	Main: 13.2 V ⎓ 5 A USB: 5V⎓3A 9V⎓2A 12V⎓1.5A
Voltage	13.2 ± 0.1 V
Rated Power	66 W

APP
APP Specifications
Video Transmission System	USB Transmission
Name	Autel Explorer
Live View Quality	Remote Controller: 720p@30fps Autel Explorer: 1080p@30fps
Latency (depending on environmental conditions and mobile device)	120 – 130 ms
Max Live View Bitrate	40Mbps
Operation system	IOS Android

SUPPORTED SD CARDS
SD Cards
Supported SD Cards	Micro SD™ Supporting Micro SD with capacity up to 256 GB and R/W speed up to UHS-I Speed Grade 3
Recommended microSD Cards	32G Sandisk V30 Sandisk Extreme V30 Pro 64G Sandisk Extreme Pro V30 128G Sandisk Extreme V30 Sandisk Extreme Pro V30 Kingston Canvas Go! Kingston Canvas React
